12G HD SDI Cables - Mini RG59
Cable Evolution 12GHz 4K UHD SDI cables are the next-gen Mini RG59 BNC cables. Designed to handle 12GHz 4K UHD signals up to 150 feet and 3G HD SDI up to 300 Feet. Our 12G UHD SDI cables provide the critical link between your switchers, cameras and other 4K video equipment. Cables are stripped with our high speed automatic cable stripper offering precision stripping. Hand assembled by our technicians featuring 4855R 4K Ultra-High-Definition Mini-RG59 coaxial cable and matching BNC, HDBNC and Din 1.0/2.3 connectors for unsurpassed 12G-UHD SDI performance.
Features
- Designed for UHD and 4K Video Transport
- 12 GHz, 4K UHD Precision 75-Ohm Video Cable
- Optimized Transmission Distance for UHDTV
- Transmits up to 149 ft @ 12G
- Return Loss: Guarantees -15 dB RL from 4.5 to 12GHz
- Meets SMPTE 424M, ST 2081-1 and ST2082-1 Standards
Specifications
- Belden 12G SDI Coax Cable with PVC Jacket in various colors
- 12G SDI Rated BNC, HD BNC or Din 1.0/2.3 Connectors
- Optional Strain Relief boots
- Compatible with 12G SDI single link format devices
- Nominal Impedance: 75Ω
- Conductor: Silver Plated Copper
- Insulation: Gas Injected Foam HDPE
- Outer Shield: Duofoil bonded to the Core + Tinned Copper Braid Shield
- Conductor DC Resistance: 19.700 DCR@20°C(Ohm/1000ft)
- Transmission Distance: 12G signals up to 149 feet, 6G up to 215 feet, and 3G up to 310 feet
Purchase our cables at the below websites
Offers full customization to meet your exact needs
Real time inventory and full selection of stock lenghts with the ease of Amazon checkout.
There are no products listed under this category.
